5 Foot WBC-PRO-QUAD-MINI Cable Pair with Amphenol KM2P-AU 3.5mm TS and Rean RTP3C-B 3.5mm TRS Connectors

$51.90

This is a custom built cable using WBC-PRO-QUAD-MINI wire with Amphenol KM2P-AU 3.5mm TS and Rean RTP3C-B 3.5mm TRS connectors.

SKU WBC-PRO-QUAD-MINI - (KM2P-AU)(RTP3C-B)- 5 Foot - 2 Cables Categories , Brand:

Worlds Best Cables 10 year warranty for all audio cables

An industry leading 10 Year Replacement Warranty, and unlike our competitors with preconditions or fineprint, you get a no-nonsense, all covered 10 Year Replacement Warranty for your WBC cable.

All our bespoke cables are professionally soldered using WORLDS BEST CABLES proprietary 4% silver solder blend & a nitrogen-assisted soldering process unique to us. This improves the integrity of solder joints over traditional methods.

Description

WBC-PRO-QUAD-MINI

WBC-PRO-QUAD-MINI is truly the most silent and the most flexible star-quad mini cable in the market. It boasts a tough UV protected outer jacket, a dense braided shield (above 98% coverage). The cable is comprised of four Copper cores, each 0.08mm in diameter, using 99.99% Oxygen Free Copper (OFC). The total diameter of 2 cores is 22AWG, while a single core stands at 25AWG. Excellent shielding coupled with the star-quad design totally cancels out all EMI and RFI this stage-ready cable will encounter, resulting in the purest form of signal transmission. The WBCPRO-QUAD-MINI’s performance is superior to industry leaders such as the Mogami 2893.

The WBC Pro cable range is designed based on science, engineered and manufactured in-house to the highest quality in the industry, and sold at prices that are unbeatable by the “pro” competition. These high-value, high-quality cables will not break your bank and the integrity of your creative process. With WBC-PRO you are buying a product made with love and the utmost care for quality. WBC Pro, the only cable you will ever need!



Amphenol Corporation

Amphenol is the World’s Leading Industrial Connector Manufacturer. Amphenol is an almost 100-year-old, NYSE-listed, legendary American brand. They are trusted for generations by the telecommunications, aerospace, electronics, and military industries. You get the best quality when you select Amphenol.



Rean

REAN is a global brand from the Neutrik Group, marrying over 45 years of precision engineering know-how with our own dedicated state-of-the-art production facilities.

REAN offers designers of audio, video and lighting products a comprehensive range of connectors featuring ultra-robust, high-reliability designs, that promise unrivalled cost-performance ratios, backed by a truly global supply chain and experienced regional sales network.



All Worlds Best Cables are professionally soldered using our proprietary 4% silver solder blend and a nitrogen-assisted soldering process unique to us, exceeding industry standards by improving the integrity of solder joints over traditional methods.

This WBC cable uses WBC-PRO-QUAD-MINI wire with Amphenol KM2P-AU 3.5mm TS and Rean RTP3C-B 3.5mm TRS connectors.

Additional information

Weight0.200 kg
Configuration
Part No.WBC-PRO-QUAD High-Definition Ultra EMI/RFI Rejecting Microphone Cable
Number of Conductors4 (Four) – Star Quad structure
Conductor Details44 X 0.08mm – 99.99% High Purity OFC (Oxygen Free Copper) X 4 Cores
EMI rejection compared to the”standard” industry cablesBetter than the Mogami 2534 and the Canare L-4E6S
Capacitance compared to the “standard” industry cablesApproximately same as the Mogami 2534 and far less than the Canare
L-4E6S
Conductor Size (AWG)21AWG (Quad configuration)
Twist Pitch12.5mm (0.49 Inch)
Conductor Overall Diameter1.3mm
Conductor Insulation MaterialFPE (Formed Polyethylene)
Shield TypeHigh Density Woven Shield (Braided Shield)
Shield CoverageGreater than 98%, the most dense coverage in the market (magnified x3)
Shield Construction128 X 0.10mm 99.99% OFC woven (braided) shield
Overall Diameter (Including UV Resistant Polyester Braid)7mm
PVC Jacket MaterialTough PVC – Stage Ready!
ELECTRICAL & MECHANICAL CHARACTERISTICS
Capacitance at 1kHz, 20°C
Capacitance – Conductor to Conductor65pF/m (19.82pF/Ft)
Capacitance – Conductor to Shield115pF/m (35.06pF/Ft)
DC Resistance at 20°C
Inner Conductor0.06Ω/m (0.02Ω/ft)
Shield0.01Ω/m (0.003Ω/ft)
Inductance between Conductors at 1kHz. 20°C0.3µH/m (0.09µH/ft)
Electrostatic Noise15mV Max
Electromagnetic Noise0.02mV Max
Microphonics at 50KΩ Load90mV Max
Flex Life60 000 cycles (Stage Ready!)
Tensile Strength915N
Applicable Temperature-40°C to 75°C / -40°F to 167°F
Brittle Point-89°C / -128.2°F
Physical Handling AttributesEngineered to be the most flexible, braided quad cable in the market



WBC Pro Quad specs ver2
